Created on: 21 March 2018
2N7000 pinout of N-Channel MOSFET in a TO-92 though-hole mounting package. This is a small signal 200mA 60V transistor of the MOSFET type with maximum on resistance (Drain-Source) of 5Ω.
NTE offers high quailty JFETS, Field Effect Transistors (FET, Includes Small-Signal MOSFETs). Buy N-Channel MOSFET, 500 mA, 60 V, 3-Pin TO-92 ON Semiconductor BS170. Browse our latest MOSFETs offers. Free Next Day Delivery available. 10pcs BS170 MOSFET Transistor 500mA 60 Volts N-Channel Enhancement Mode FET TO92. 5pcs IRF9540 IRF9540N P-Channel Power MOSFET 23A 100V TO-220 IR Transistor. 20pcs IRF3205 IR MOSFET N-CHANNEL 55V/110A TO-220 HEXFET Power Transistor IRF. $4.25 shipping ' IRFP140 & IRFP9140 (1 Pair. Bridgold 50pcs 10Types IRF Series Mosfet transistors Assortment Kit, Including IRFZ44 IRF510 IRF520 IRF530 IRF540 IRF640 IRF740 IRF840 IRF3205 IRF9540 Package 4.6 out of 5 stars 34. FAIRCHILD SEMICONDUCTOR BS170D26Z N CHANNEL MOSFET, 60V, 500mA, TO-92 (10 pieces).
Available from various manufacturers:
2N7000 Pinout, Symbol and TO-92 Package
P Mosfet To92
Below is the symbol of the 2N7000 N-Channel MOSFET and pinout for its TO-92 transistor package.
2N7000 Pinout N-Channel TO-92 MOSFET
- S – Source – equivalent of emitter on NPN transistor
- G – Gate – equivalent of base on NPN transistor
- D – Drain – equivalent of collector on NPN transistor
2N7000 Basic Characteristics
Channel Mosfet To 92
Below are some of the basic characteristics of a 2N7000 transistor, see the 2N7000 datasheet from one of the various manufacturers listed near the top of this page for more details.
| Maximum Continuous Drain Current | 200mA |
| Maximum Drain Source Voltage | 60V |
| Maximum Drain Source Resistance | 5Ω |
| Gate Threshold Voltage (VGS) | Min = 0.8V | Max = 3V |
| Maximum Power Dissipation | 400mW |
